❖Features
New Eberspächer D2L AS3 – Diesel Heater
With the third generation of the Airtronic, Eberspächer is launching acompletely new product family of air heaters for commercial and specialvehicles.
It combines high heating performance with a very compact design, quietoperation, automatic altitude
Adjustment up to 5,500 m* and flexible installation. The Eberspächer EasyStartPro and EasyStart Web control units offer particularly convenient anduserfriendly operation for the Airtronic. All other control units are alsocompatible.
The Airtronic 3 complements Eberspächer’s segment-focused product strategyperfectly, boasting a new combustion chamber concept and other new features,including a new casing design.
And of course, the enhancements previously made to the Airtronic 2 areincluded in the thirdgeneration heaters as well.
Eberspächer Airtronic D2L AS3 12v 1 Outlet E/S Pro Kit
ADDITIONAL FEATURES:
- Patented housing design for improved plagiarism protection
- Lifetime of up to 5,000 operating hours due to brushless motor
- Backward compatibility through carry-over connections
- Sensor-controlled, optimized start-up sequences through measurement of environmental parameters
- Optimized heat air flow due to improved heat exchanger
- Maximum control with EasyStart Pro and EasyStart Web
- Compatibility with all other control units
- Diagnostics and parameter assignment via EasyScan
- Can also be integrated into on-board systems via CAN (12/24V), LIN (12V), S+(12/24V) interfaces
ADVANTAGES
- High heating power, yet compact design
- Automatic altitude adjustment up to 5,500 m*
- Flexible installation with 90° tilt possible to either side
- Stepless heating performance control ensures quiet operation
Eberspächer 10L Diesel Fuel Tank
- It has an screw cap opening at the top, plus the outlet to allow the tank to be placed in either direction.
- Slim design makes the tank easy to store
- Very light weight when empty
- Secure lid
Kit inclusion:
- 1 x Airtronic D2L AS3 D/Heater Body
- 1 x Easystart Pro Controller
- 1 x Mounting Plate
- 1 x Fuel Metering Pump Inc Pump Holder
- 1 x 6mtr Fuel Line
- 1 x 2m S/Steel Exhaust Pipe & Silencer
- 1 x 0.5m Air Intake Tube
- 1 x 2 Meters 60mm Ducting
- 2 x 60mm Vent Flanges & Flat Vent Covers
- 1 x Wiring Harness (plug & play throughout heater kit) & 6m Twin Core Power Supply Cable
- 1 x Miscellany Pack, Screws & Washes, Clamps, P Clips, Zip Ties, Fuel Line Joiners, Warranty Card, QR Code For Digital
- 1 x 10L Diesel Fuel Tank
|
❖Specifications
Brand | Eberspacher
Model | 292113000019
Product Type | Diesel Heater
Voltage | 12V
Fuel | Diesel
Heating Capacity (kw) | 0.85 – 2.2
Heating Air Flow Rate * (kg/h) | max. 105
Electaical Power Consumption (W) | max. 28
Fuel Consumption (l/h) | 0.1 – 0.27
Operating Temperature Heater (˚C) | -40 to +70
Auto dimmer function on controller | Standard
Main Dimensions LxWxH (mm) | 310x115x122
Net Weight (kg) | 2.5
Manufacturers Warranty | 3 years
