Quick Release Adjustable Leg Aluminium Foot – Adjustable Length Size 3 to 5
Quick Release Adjustable Leg with Aluminium Foot – Weld on – Adjustable Length version – Aluminium construction.
Size 3 to Size 5
How to Use:
- Pull handle to swing leg into lowest lock position (variable) then take up support weight using hex head handle.
- Support capacity varies depending on angle of leg and surface grip of foot.
- Generally a more vertical position will give greater load capacity but will reduce stability.
Note: ALQRs are stabilising legs. They are not designed to be used as levelling legs.
Product Code: AL-ALQR3-5
Closed Height: 520mm
Extension Leg Max.: 260mm
Lift Leg Max.: 240mm
Extended Height: 1020mm
Replaces: ALQR3, ALQR4, ALQR5
Foot: Large Aluminium Foot Plastic Coated
Finish: Aluminium Hammertone Finish
Unit Weight: 8.00kg
